ESC8000 G4

High-density 4U GPU server support 8 GPUs

·       Powered by Intel® Xeon® Scalable Platform

·       High-density GPU server with hybrid computing power

·       ASUS-patented Adaptable Topology design

·       Scalable design for growing workloads

·       Comprehensive IT Infrastructure Management Solution

·       Efficient cooling with hot-swappable redundant fans and dedicated air tunnels

·       Exclusive thermal radar technology for energy efficiency

·       Simplified maintenance and management



·       Supports 100Gbps Intel® Dual Embedded Omni-Path Architectur

  • Processor / System Bus
    2 x Socket P (LGA 3647) Intel® Xeon® Scalable Processors Family Intel® Xeon® Scalable Processors Family with OMNI-PATH FABRIC *Refer to support page for more information
  • Core Logic
    Intel® Lewisburg PCH C621
  • Memory
    Total Slots : 24 (6-channel per CPU, 12 DIMM per CPU) Capacity : Maximum up to 3072GB RDIMM Memory Type : DDR4 2666/2400 /2133 RDIMM DDR4 2666/2400 /2133 LRDIMM DDR4 2666/2400 /2133 LR-DIMM 3DS Memory Size : 64GB, 32GB, 16GB, 8GB RDIMM 64GB, 32GB LRDIMM 128GB, 64GB LR-DIMM 3DS * Refer to support page for more information
  • Expansion Slots
    Full-length/Full-height 8 x PCI-E x16 (Gen3 x16 link) , FH, FL Half-length/Low-profile Rear: Dual root topology: 2 x PCI-E x16 (Gen3 x 16 link), LP, HL or Single root topology: 1 X PCI-E x16 (Gen3 x16 link), LP, HL Front: 1 x PCI-E x8 (Gen3 x8 link) , LP, HL
  • Storage
    SATA Controller : Intel® C621 8 x SATA3 6Gb/s ports + 2 x M.2 connector (SATA 6Gb/s & PCI-E Gen3 x4 link 22110/2280/2260) or 6 x SATA3 6Gb/s ports + 2 x NVMe drives + 2 x M.2 connector (SATA 6Gb/s & PCI-E Gen3 x4 link 22110/2280/2260) Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows) (Support Software RAID 0, 1, 5, 10 ) Intel®VROC (For Linux/Windows) (Support Software RAID 0/1 ) SAS Controller : ASUS PIKE II 3008 8-port SAS HBA card ASUS PIKE II 3108 8-port SAS HW RAID card 12G SAS Support
  • HDD Bays
    8 x Hot-swap 2.5″ HDD Bays
  • Networking
    1 x Dual Port Intel I350-AM2 Gigabit LAN controller + 1 x Mgmt LAN
  • Graphic
    Aspeed AST2500 with 64MB VRAM
  • Front I/O Ports
    2 x USB 3.0 ports 2 x USB 2.0 ports 1 x VGA port 1 x COM port
  • Rear I/O Ports
    2 x RJ-45 GbE LAN ports 1 x RJ-45 Mgmt LAN port
  • Switch/LED
    Front Switch/LED: 1 x Q-Code/Port 80 LED 1 x Power switch/LED 1 x Location switch/LED 1 x HDD Access LED 1 x Message LED Front Switch/LED: 1 x Q-Code/Port 80 LED 1 x Power switch/LED 1 x Location switch/LED 1 x HDD Access LED 1 x Message LED 2 x LAN LED
  • OS Support
    Windows® Server 2016 Windows® Server 2012 R2 RedHat® Enterprise Linux SuSE® Linux Enterprise Server CentOS Ubuntu VMware Citrix XenServer Fedora
  • Management Solution
    ACC On-Board ASMB9-iKVM for KVM-over-IP
  • Regulatory Compliance
    BSMI, CE, FCC(Class A)
  • Dimensions
    798mm x 439mm x 175.6mm
  • Form Factor
    4U
  • Power Supply
    2+1 Redundant 1600W 80PLUS Platinum Power Supply; 100-127 / 200-240Vac, 12.9 / 9.5A(for each inlet), 47-63Hz, Class I
  • Environment
    Operation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing)
